| Quantity: | |
|---|---|
YXF-9F-B35F-60D / YXF-9F-B53F-60D
YXFiber
SFP
155M
60KM
Duplex LC
Product Description
| Part No. | Data Rate | Wavelenth | Distance | Output Power (dBm) | Sensitivity (dBm) | Connector | Temp(℃ ) |
| 1X9 BIDI | 155M | TX1310/RX1550 | 20KM | -12--3 | ≤-34 | SC/FC/ST | 0~70 |
| 1X9 BIDI | 155M | TX1550/RX1310 | 20KM | -12--3 | ≤-34 | SC/FC/ST | 0~70 |
| 1X9 BIDI | 155M | TX1310/RX1550 | 40KM | -7-0 | ≤-35 | SC/FC/ST | 0~70 |
| 1X9 BIDI | 155M | TX1550/RX1310 | 40KM | -7-0 | ≤-35 | SC/FC/ST | 0~70 |
| 1X9 BIDI | 155M | TX1490/RX1550 | 80KM | -2-1 | ≤-37 | SC/FC/ST | 0~70 |
| 1X9 BIDI | 155M | TX1550/RX1490 | 80KM | -2-1 | ≤-37 | SC/FC/ST | 0~70 |
| 1X9 BIDI | 1.25G | TX1310/RX1550 | 20KM | -9--3 | ≤-24 | SC/FC/ST | 0~70 |
| 1X9 BIDI | 1.25G | TX1550/RX1310 | 20KM | -9--3 | ≤-24 | SC/FC/ST | 0~70 |
| 1X9 BIDI | 1.25G | TX1310/RX1550 | 40KM | -5-0 | ≤-25 | SC/FC/ST | 0~70 |
| 1X9 BIDI | 1.25G | TX1550/RX1310 | 40KM | -5-0 | ≤-25 | SC/FC/ST | 0~70 |
| 1X9 BIDI | 1.25G | TX1490/RX1550 | 80KM | -2-1 | ≤-27 | SC/FC/ST | 0~70 |
| 1X9 BIDI | 1.25G | TX1550/RX1490 | 80KM | -2-1 | ≤-27 | SC/FC/ST | 0~70 |
| 1X9 DUAL | 1.25G | 1310nm | 20KM | -12--2 | ≤-34 | SC/FC/ST | 0~70 |
| 1X9 DUAL | 1.25G | 1310nm | 40KM | -7-0 | ≤-35 | SC/FC/ST | 0~70 |
| 1X9 DUAL | 1.25G | 1550nm | 80KM | -2-1 | ≤-37 | SC/FC/ST | 0~70 |
| 1X9 DUAL | 1.25G | 850nm | 550M | -9--3 | ≤-18 | SC/FC/ST | 0~70 |
| 1X9 DUAL | 1.25G | 1310nm | 20KM | -9--3 | ≤-24 | SC/FC/ST | 0~70 |
| 1X9 DUAL | 1.25G | 1310nm | 40KM | -5-0 | ≤-25 | SC/FC/ST | 0~70 |
| 1X9 DUAL | 1.25G | 1550nm | 80KM | -2-1 | ≤-27 | SC/FC/ST | 0~70 |
| 1X9 DUAL TTL | 0-2M | 1310nm | 20KM | -4--10 | ≤-16 | SC/FC/ST | 0~70 |
