YXF-S28-DXXL-15D
YXFiber
YXF-S28-DXXL-15D
SFP28
25G
Duplex LC
Cisco, Mikrotik, HPE, TP LINK, HP, D-Link, Juniper, Ubiquiti, Huawei, Dell, Aruba, Finisar, ZTE, lntel, Avago, Arista, Mellanox, Brocade, QNAP, Fortinet
* Up to 25.78 Gb/s bi-directionaldata links
* Hot-pluggable SFP28 footprint
* Built-in digital diagnostic functions
* 1563.86nm~1528.77nm EML laser transmitter
* LC connector RoHS compliant
* Metal enclosure, for lower EMI
* +3.3V power supply
* Operating temperature range: 0°C to 70°C
| Model | YXF-S28-DXXL-15D | Distance | 15km |
| Form Factor | SFP28 | Max Data Rate | 25G |
| Wavelength | 1563.86nm~1528.77nm | Transmitter Type | EML |
| Media | SMF | Receiver Type | PIN |
| Output Power (dBm) | 6~-3dBm | Sensitivity (dBm) | ＜-19dBm |
| Voltage | 3.3V | Temperature Range (℃） | 0-70 |
| Connector | LC | DDM/DOM | √ |
| Protocols | IEEE802.3ah 1000Base-BX | Warranty | 1 years |
