InfiniBand MMS4X00-NM Compatible OSFP 800G DR8 Finned Top PAM4 2 x DR4 1310nm 500m DOM Dual MPO-12/APC SMF NDR Optical Transceiver Module

800GBASE-2xDR4+ OSFP PAM4 1310nm 500m DOM Dual MTP/MPO-12 APC SMF Transceiver Module Finned Top

Name: 800GBASE-2xDR4+ OSFP PAM4 1310nm 500m DOM Dual MTP/MPO-12 APC SMF Transceiver Module Finned Top
Brand: YXFiber
Rating: 5.0 (48 reviews)

Features：

Tested in Targeted Switches for Superior Performance, Quality, and Reliability.
Class1/1M Standard Product, Compliant with RoHS Environmental Protection Standards (Lead-Free).
DDM(Digital Diagnostic Monitoring) Supported.
Provide Professional Compatibility and Parameter Test Reports.
30-Day Free Return, 3-Year Warranty, Lifetime After-sales Technical Support.

Quantity:
Availability:





Inquire

Model:
YXF-OSFP-800G-2DR4+
Brand:
YXFiber
Form Factor:
OSFP
Data Rate:
800G
Model:
2xDR4+
Distance:
500M
Connector:
MPO-12 APC
Compatible Brand:
Cisco, Mikrotik, HPE, TP LINK, HP, D-Link, Juniper, Ubiquiti, Huawei, Dell, Aruba, Finisar, ZTE, lntel, Avago, Arista, Mellanox, Brocade, QNAP, Fortinet

800GBASE-2xDR4+ OSFP PAM4 1310nm 500m DOM Dual MTP/MPO-12 APC SMF Transceiver Module，Finned Top

The YXFiber’s YXF-OSFP-800G-2DR4+ optical transceiver module is designed for 800GBASE throughput, transmission distances up to 500m, and single-mode fiber (SMF) via dual MTP/ MCO-12 connectors. The YXF-OSFP-800G-2DR4+ module can convert 8 channels of 106.25Gb/s electrical data into 8 channels of 106.25Gb/s optical signals. Similarly, it converts the 8-channel 106.25Gb/s optical signal into 8-channel electrical data output at the receiving end. It is designed to withstand the widest range of external operating conditions, including temperature, humidity and electromagnetic interference.

Form Factor	Twin-port OSFP	Distance	500m
Wavelength	1310nm	Connector	Two MPO-12/APC
Power Consumption	≤16W	Transmitter	EML
Receiver	PIN	Media	SMF
Modulation(electrica	8x106.25Gb/s PAM4	Modulation(Optical )	Two ports 4x106.25Gb/s PAM4
Case Temperature(°C)	0 to 70°C (32 to 158°F)	Warranty	3 Years
