Analysis of the Core Advantages of BIDI SFP Optical Modules

For long-distance communications, laying optical fiber is a cumbersome, time-consuming, labor-intensive, and costly undertaking. Therefore, minimizing the number of optical fibers used in long-distance communications is a highly desirable and compelling goal. This is why BIDI technology was born and quickly matured and entered commercial use. Traditional optical modules require two optical fibers (one for transmitting and one for receiving) for bidirectional communication. However, BIDI (Bidirectional) SFP optical modules enable bidirectional data transmission using only a single fiber, saving half the fiber resources. This is the greatest advantage of BIDI SFP optical modules.

1. What is a BIDI SFP optical module?

The BIDI SFP optical module utilizes wavelength division multiplexing (WDM) technology, using two different wavelengths (such as 1310nm and 1550nm) for transmission and reception on a single optical fiber. The module's integrated MUX and DEMUX multiplexing and demultiplexing functions prevent interference between the two optical paths, thus achieving single-fiber bidirectional transmission. Currently, BIDI SFP optical modules have been widely used in various network scenarios due to their unique advantages.

2. Advantages of BIDI SFP Modules

2.1 Saving Fiber Resources

This is the biggest advantage of BIDI modules. Traditional dual-fiber optical modules require two optical fibers for communication: one for transmitting and one for receiving. These two fibers form a loop for data transmission. However, BIDI modules are different. Due to their integrated WDM components, BIDI modules only require a single fiber to simultaneously transmit and receive optical signals, forming a loop for data transmission. This saves 50% of fiber resources, allowing more services to be transmitted with the same fiber resources. They also offer irreplaceable advantages in long-distance transmission, where laying fiber is expensive.

2.2 Reducing Cabling Costs

For the same number of services, BIDI optical modules can save 50% of fiber resources compared to conventional dual-fiber SFP optical modules. This means a 50% reduction in cabling workload, a 50% reduction in raw material costs, and a 50% reduction in space required for cabling planning, significantly reducing cabling costs.

2.3 Simplifying Network Cabling and Reducing Operation and Maintenance Difficulties

Reducing fiber usage significantly reduces cabling network complexity, speeding up construction progress and reducing operational and maintenance difficulties later on. This facilitates network operation and troubleshooting, reducing the probability of network failures.

3.Practical Application Scenarios of BIDI SFP Optical Modules

3.1 5G Fronthaul Networks

In 5G fronthaul networks, fiber resources can sometimes be limited due to insufficient planning. Using conventional dual-fiber modules can lead to insufficient fiber. BIDI effectively solves this problem without compromising network performance and stability, and reducing the additional costs associated with re-laying fiber.

3.2 Enterprise Network Capacity Expansion

In enterprise networks, when additional network connectivity is needed but fiber racks and ducts are insufficient, BIDI technology can leverage existing fiber networks for network expansion without laying new fiber. This solves cabling difficulties and reduces losses caused by service interruptions.

4.Considerations for Selecting BIDI Modules

Great advantages are always accompanied by disadvantages, and this applies to BIDI SFP optical modules as well. These disadvantages can significantly impact the module's proper operation. Therefore, when selecting and deploying BIDI SFP modules, we must consider the following points:

4.1 Use in Pairs

Because BIDI optical modules differ from conventional SFP optical modules in their implementation principle, incorporating wavelength division multiplexing technology, and because light propagation is reversible, optical signals transmitted by BIDI modules with the same wavelength can interfere with each other within the optical fiber, resulting in signal incompatibility and impaired link communication. Therefore, BIDI modules must be used in pairs, with matching wavelengths on both ends (1310nm/Tx, 1550nm/Rx on one end, and the opposite on the other end).

4.2 Ensure Fiber Quality

Because BIDI optical modules use different wavelengths, and light of different wavelengths experiences different transmission losses in optical fibers, using poor-quality fiber can sometimes result in a situation where one end has an optical signal but the other does not, preventing the two devices from establishing a connection. Therefore, when using optical modules, it is crucial to use high-quality fiber to avoid excessive fiber attenuation, which can affect the module's proper function.

Conclusion

BIDI SFP optical modules cleverly utilize wavelength division multiplexing technology to achieve bidirectional communication over a single optical fiber, offering multiple advantages such as conserving fiber resources, reducing cabling costs, and simplifying network wiring. For networks facing fiber resource constraints yet needing to expand network capacity, BIDI technology provides an efficient, cost-effective, and reliable solution, meeting network expansion needs at a lower cost and with higher efficiency. When choosing your next network upgrade solution, BIDI SFP modules are undoubtedly a worthwhile option.
