In the digital age, fiber optic cables have become the backbone of modern communications, enabling lightning-fast data transmission and unparalleled network performance. However, the high speed and data capacity of fiber optic cables are accompanied by natural fragility because they utilize glass within their physical makeup. To ensure reliable connectivity and minimize downtime, network administrators must choose between two primary designs: armored and unarmored fiber optic cables.
An armored fiber optic cable is a type of cable that has a protective armor wrapped around the fiber cable core. This armor is a metal sheathing—typically made of steel, aluminum, or flexible metal tubing—designed to protect the delicate optical fibers from extreme weather, physical damage, and mechanical stress.
The typical structure of an armored cable includes several protective layers:
Core Fiber: The central component that transmits data as light pulses; it can be single-mode for long distances or multimode for high volumes over short distances.
Buffer Tube: Encases the fiber for extra protection, utilizing tight-buffered designs for indoors or loose-tube designs for outdoor moisture protection.
Strength Members: Usually made of aramid yarn (Kevlar) to enhance tensile strength and prevent the fiber from stretching or breaking during installation.
Armoring Layer: The unique feature made of materials like corrugated steel tape (CST) or interlocking aluminum, providing resistance to crushing and rodent attacks.
Outer Jacket: A protective sleeve (often PVC, Polyethylene, or TPU) that shields the cable from UV rays, moisture, and chemicals.
Armored cables vary based on the material and design of the protective layer:
Aluminum Interlocking Armor (AIA): Constructed of aluminum tape helically wrapped around the cable, offering flexibility and mechanical protection in industrial settings.
Corrugated Steel Tape (CST): Composed of coated, corrugated steel folded longitudinally around the cable, providing excellent crush resistance and moisture protection for direct burial.
Stainless Steel MicroArmor: A patented technology that is 65% lighter and 75% smaller than traditional AIA cables while offering superior strength and flexibility.
Steel Wire Armor (SWA): Utilizes round steel wires to provide the highest level of mechanical protection and tensile strength.
Unarmored fiber optic cables, also known as standard fiber patch cables, lack the additional metal or reinforced protective layer. They feature a simpler design composed of the fiber core, strength members (like aramid yarn), and a single protective outer jacket made of plastic or polymer. These cables rely on their basic jacket for protection, making them lighter and more flexible but more vulnerable to physical threats.
Armored cables offer enhanced protection against physical threats such as crushing, cutting, and rodent bites. They are designed to withstand harsh environmental conditions, including exposure to moisture and extreme weather.
In contrast, unarmored cables are susceptible to cuts, crushing, and rodent damage. Even pulling or twisting a little too much during installation can break the internal glass fibers.
Unarmored Cables: They are generally more affordable upfront because they lack specialized armoring materials. However, for harsh-environment applications, unarmored cables require the installation of protective conduits. This process involves laying pipes first and then pulling wires, which effectively doubles the cost of labor and materials.
Armored Cables: While they have a higher initial purchase cost, they are often more cost-effective in the long run. They can be direct-buried or placed in trays without conduit, and their high durability reduces the frequency of expensive repairs or network outages, which can cost businesses thousands of dollars per minute.
Unarmored cables are sleek, lightweight, and highly flexible. This makes them easier to navigate through congested pathways, narrow conduits, and tight indoor spaces. Armored cables are typically heavier, bulkier, and stiffer. They require more effort and sometimes specialized machinery to handle and deploy. However, Stainless Steel MicroArmor is an exception, offering flexibility similar to unarmored wires while maintaining full armored protection.
While optical fibers use light and are inherently resistant to electromagnetic interference (EMI), the overall cable system can still be affected by external factors.
EMI Shielding: The metal armor layer acts as a barrier against external electromagnetic fields generated by heavy machinery or power lines.
Grounding: Many armored cables include grounding capabilities to dissipate electrical surges or interference, further protecting signal integrity.
Physical Integrity: By preventing microfractures and core misalignment caused by physical stress, armored layers ensure consistent, stable data transmission.
Table 1 Performance Comparison Table
Feature | Armored Fiber Optic Cable | Unarmored Fiber Optic Cable |
Protection | High (Crush, Rodents, Impact, Moisture) | Basic (Vulnerable to physical hazards) |
Cost | Higher upfront; Lower maintenance | Lower upfront; Higher labor (if conduit needed) |
Installation | Challenging (Heavier, Stiffer) | Easier (Lightweight, Flexible) |
Usage | Outdoor, Industrial, High-traffic | Indoor, Office, Data Center |
Durability | Long lifespan in harsh conditions | Sufficient for controlled environments |
Weight | Bulkier and heavier | Slimmer and lighter |
In manufacturing plants, oil and gas refineries, and mining operations, cables face vibration, extreme temperatures, and corrosive substances. Armored cables (especially those with TPU jackets) are ideal for these settings as they resist abrasion, chemicals, and mechanical strain from heavy machinery.
The telecommunications segment is a primary driver for armored cables due to the rollout of 5G networks and fiber-to-the-home (FTTH) initiatives. These cables provide essential protection against rodents and environmental factors in remote or physically demanding areas, ensuring uninterrupted service for deployments worth billions of dollars.
Inside data centers, cables are often exposed under raised floors or in overhead trays where they risk accidental damage during maintenance. Indoor armored cables combine Kevlar reinforcement with stainless-steel tubing to prevent cutting and abrasion while maintaining enough flexibility for high-density networking.
For military and defense applications, the operational readiness of communication systems in combat zones or naval vessels is paramount. Armored cables offer a tamper-proof design that deters unauthorized access or sabotage, providing the physical security required for sensitive government data.
Direct burial armored cables feature heavy steel armor and UV-resistant jackets to survive harsh soil conditions and heavy loads without conduits. In submarine environments, specialized armored cables endure immense water pressure (up to 6000 psi) and corrosion at depths of over 8000 meters.
Matching environmental conditions with the cable's protective structure is the key to an informed decision
High-Risk Environments: Your cables are exposed to physical damage on construction sites, industrial plants, or outdoor areas.
Outdoor or Underground: You are performing direct burial or installing cables in areas prone to extreme weather.
Rodent Infestation: You are deploying in rural, agricultural, or urban underground environments where animals may chew cables.
Security Needs: Your network requires maximum security against tampering (e.g., military or financial networks).
Long-Term ROI: You want to minimize future maintenance and replacement costs despite a higher initial investment.
Controlled Indoor Settings: Offices, residential buildings, and server rooms with minimal physical risks.
Budget Constraints: Low-cost initial deployment is a top priority, and the environment is safe.
Space Limitations: You need highly flexible, slim cables for tight pathways, complex routing, or dense server racks.
Short-term Deployments: Projects where long-term environmental durability is not a concern.
To ensure long-term performance, follow these guidelines during installation:
Bend Radius: Strictly follow the manufacturer's minimum bend radius (typically 10D to 20D); exceeding this can damage internal fibers.
Pull Strength: Never pull directly on the optical fibers; pull from the middle of the cable to reduce stress and use the armor or strength members to bear the load.
Grounding: Properly bond and ground the metal layers of armored cables to protect against lightning strikes and electrical interference.
Pathway Prep: Inspect paths for debris or obstacles and leave extra length (service loops) at connection points for future maintenance.
Testing: Perform optical testing (OTDR or power meter) after installation to verify signal continuity and insertion loss.
