Views: 999 Author: Anna Publish Time: 2025-10-30 Origin: Site
1. What is a 100G BIDI transceiver?
1.1 100G BIDI Transceiver Definition
1.2 Key Technologies of 100G BIDI Transceivers
2. What types of 100G BIDI transceivers are available?
2.1 YXF-Q28-B23L-10D/YXF-Q28-B32L-10D
2.2 YXF-Q28-B23L-20D/YXF-Q28-B32L-20D
2.3 YXF-Q28-B49L-30D/YXF-Q28-B94L-30D
2.4 YXF-Q28-B49L-40D/YXF-Q28-B94L-40D
3. What are the application areas of 100G BIDI transceivers?
3.1 100G BASE Ethernet
3.2 Switch/Router
3.3 Campus Network
It adopts single-fiber bidirectional transmission (WDM) technology, requiring only one fiber to complete bidirectional data transmission, saving 50% of fiber resources; it features a high-density design, using a small-size QSFP28 package, compatible with high-density switch ports; it has strong compatibility, supporting interconnection with mainstream brand switches, allowing for smooth upgrades to existing networks; it supports transmission distances from 100m to 80km, suitable for solutions in data centers and telecom operators.
The key technology used in the 100G QSFP28 BIDI optical module is wavelength division multiplexing (WDM). Traditional optical modules require two fibers to handle "transmit" and "receive" respectively, while BIDI modules, through WDM technology, allow a single fiber to simultaneously carry two different wavelengths of optical signals, such as an uplink wavelength of 1270nm and a downlink wavelength of 1330nm. The two wavelengths do not interfere with each other, like dividing a highway into "two lanes," achieving efficient coexistence.
PAM4 modulation addresses the bandwidth bottleneck faced by traditional NRZ modulation (two-level 0/1) at high speeds. PAM4 (four-level pulse amplitude modulation) improves efficiency through "four-lane parallel" modulation; each symbol carries 2 bits of information, doubling the speed compared to NRZ; it is compatible with 50Gbps single wavelengths, easily achieving a total bandwidth of 100G.
YXFiber's YXF-Q28-B23L-10D/YXF-Q28-B32L-10D can provide up to 10 kilometers of 100GBase-BX throughput over single-mode fiber (SMF). It uses LC connectors and has a center wavelength of 1271nm/1331nm. This bidirectional transceiver must be used with other transceivers or network devices that have complementary wavelengths. As specified in the QSFP28 MSA, digital diagnostics are available via the I2C interface, allowing access to real-time operating parameters. With these features, this easy-to-install, hot-swappable transceiver is suitable for a variety of applications, such as 100G Ethernet, data centers, and storage area networks (SANs).
YXFiber's YXF-Q28-B23L-20D/YXF-Q28-B32L-20D can provide up to 20 km of 100GBase-BX throughput over single-mode fiber (SMF). It uses an LC connector and has a center wavelength of 1271nm/1331nm. This bidirectional transceiver must be used with other transceivers or network devices that have complementary wavelengths. According to the QSFP28 MSA specification, digital diagnostics are provided via the I2C interface, allowing access to real-time operating parameters. With these features, this easy-to-install, hot-swappable transceiver is suitable for a variety of applications, such as 100G Ethernet, data centers, and storage area networks (SANs).
YXFiber's YXF-Q28-B49L-30D/YXF-Q28-B94L-30D can provide 100GBase-BX throughput over up to 30 km of single-mode fiber (SMF). It uses an LC connector with a center wavelength of 1304nm/1309nm. This bidirectional transceiver must be used with other transceivers or network devices with complementary wavelengths. According to the QSFP28 MSA specification, digital diagnostics are provided via the I2C interface, allowing access to real-time operating parameters. With these features, this easy-to-install, hot-swappable transceiver is suitable for a variety of applications, such as 100G Ethernet, data centers, and storage area networks (SANs).
YXFiber's YXF-Q28-B49L-40D/YXF-Q28-B94L-40D can provide up to 40 km of 100GBase-BX throughput over single-mode fiber (SMF). It uses an LC connector with a center wavelength of 1304nm/1309nm. This bidirectional transceiver must be used with other transceivers or network devices with complementary wavelengths. According to the QSFP28 MSA specification, digital diagnostics are provided via the I2C interface, allowing access to real-time operating parameters. With these features, this easy-to-install, hot-swappable transceiver is suitable for a variety of applications, such as 100G Ethernet, data centers, and storage area networks (SANs).
YXFiber's YXF-Q28-B23L-80D/YXF-Q28-B32L-80D can provide up to 80 km of 100GBase-BX throughput over single-mode fiber (SMF) via LC connectors, using wavelengths of [wavelength value missing]. Supports wavelengths of 1273.54, 1277.89, 1282.26, 1286.66nm-TX/1295.56, 1300.05, 1304.58, 1309.14nm-RX (1295.56, 1300.05, 1304.58, 1309.14nm-TX/1273.54, 1277.89, 1282.26, 1286.66nm-RX). This bidirectional transceiver must be used with other transceivers or network devices with complementary wavelengths. According to the QSFP28 MSA specification, it also provides digital diagnostics via an I2C interface, allowing access to real-time operating parameters. With these features, this easy-to-install, hot-swappable transceiver is suitable for a variety of applications, such as 100G Ethernet, data centers, and storage area networks (SANs).
In Ethernet, 100G BIDI transceivers are used for 100G BASE connections. They provide 100G speeds via single-core simplex LC fiber, whereas traditional solutions require two cores. This is highly attractive for links in campus network cores and metropolitan area Ethernet aggregation, maximizing the use of existing fiber optic infrastructure and avoiding costly fiber expansion projects for speed upgrades.
In the interconnection of switch and router devices, 100G BIDI modules act as critical interfaces in device clusters, stacks, or core interconnection scenarios. They enable a single device to deploy interconnect links without increasing the number of fiber cores, improving the deployment flexibility and scalability of network devices.
The 100G BIDI optical module can make full use of existing fiber optic resources, freely upgrade old networks, and save 50% of fiber optic resources under the same bandwidth.
YXFiber remains focused on the optical module field and continuously invests heavily in new product research and development. We offer OEM and ODM services. All customers enjoy a three-year warranty and technical support after-sales service. Through years of technological accumulation, our products are compatible with almost all mainstream switch brands, such as Cisco, Huawei, Juniper, Arista, Dell, Ciena, Broadcom, and Brocade.
